SPECIFICATIONS

Brand Name: NONE

Bundle Description: 4 air spring bags universal heavy duty truck

Condition: New

Custom Bundle: Yes

Fitment Type: Direct Replacement

Gas Charged Shock: Yes

High-concerned chemical: None

Interchange Part Number: Pair car truck heavy duty lowrider air spring bag

Kit or Single Part: 4 PCS Air Shock Bag Kit

Manufacturer Part Number: 9UBOP6

Note: No Instruction included

Notice: This is aftermarket replcement part

Other Part Number: 2500 Pound Air Spring Bag 1/2"NPT Single Port

Placement on Vehicle: Left, Right, Front, Rear

Product Type: Air Suspension bag 2500lbs

Quantity: 4 piece (for rear/front left or right)

Superseded Part Number: Double Convoluted Air Ride Suspension Parts

Surface Finish: Brand New

Type: Standard 2500lb Air Shock Bag 1/2"npt Single Port

UPC: Does not apply

Item Specifications

Min height 72mm±5mm
Max height 218MM±5mm
Working stroke 146mm±5mm
Loading cap. at 3.0bar 2.88KN
Loading cap. at 7.0bar 7.25KN
Single air port size 1/2NPT
Install hole size 3/8-16UNC
Top plate diameter 113mm
Air spring bag body diameter 148mm±2mm
Air spring bag capacity 2500LBS
